US Motors 7500W 3 Phase CCP ODP Motor, 215TCZ, 1765 RPM, 10 HP, 208V-230V/460V

US Motors DJ10P2DJ
SKU EMB-DJ10P2DJ
US Motors' 7500W 3 phase CCP ODP motor with 215TCZ FRME, 1765 RPM, 10 HP, 208V-230V/460V and made for the specific requirements of centrifugal pumps where the pump impeller is mounted directly on the motor shaft. Check out more at HomElectrical today!
US Motors 7500W 3 Phase CCP ODP Motor, 215TCZ, 1765 RPM, 10 HP, 208V-230V/460V

Image may not depict product actual color, inclusions or accessories

US Motors' 7500W 3 phase CCP ODP motor with 215TCZ FRME, 1765 RPM, 10 HP, 208V-230V/460V and made for the specific requirements of centrifugal pumps where the pump impeller is mounted directly on the motor shaft. Check out more at HomElectrical today!
  • Motor Enclosure: ODP.
  • HP: 10.
  • Kilowatts: 7.5.
  • Poles: 4.
  • Number of Speeds: 1.
  • RPM: 1455/1765.
  • Hertz: 50/60.
  • Volts: 208-230/460.
  • FRME: 215.
  • Shaft Code: TCZ.
  • Mounting: Horz-Footed.
  • Motor Type: DE3.
  • Bearing: 6205-2Z-J/C3.
  • Special application close coupled pump.
  • 3 phase.
  • Open dripproof (ODP).
  • Premium efficient.
  • Westcoast shaft - footed.
  • Class F Insulation, Class B Rise At Service Factor.
  • Rolled Steel Frame.
  • Aluminum End Shields 140-250, Cast Iron End Shields 280-320.
  • Oversized Ball Bearings with Locked Shaft End Construction.
  • Premasked Mylar Nameplate.
  • F1 Assembly Position.
  • Regreasable Bearings 180 Frame & Up, Lifting Provisions 210 Frame & Up.
  • Double Shielded Bearings.
  • 40 C Ambient, NEMA Design B Performance On 60 Hertz Sine Wave Power.
  • JM Shaft For Mechanical Seal.
  • JM Shaft on 210 Frame and Smaller; JP Shaft on 250 and 280 Frame.

Similar HVAC Fan Motor Products

US Motors DJ10P2DJ Description

  • Motor Enclosure: ODP.
  • HP: 10.
  • Kilowatts: 7.5.
  • Poles: 4.
  • Number of Speeds: 1.
  • RPM: 1455/1765.
  • Hertz: 50/60.
  • Volts: 208-230/460.
  • FRME: 215.
  • Shaft Code: TCZ.
  • Mounting: Horz-Footed.
  • Motor Type: DE3.
  • Bearing: 6205-2Z-J/C3.
  • Special application close coupled pump.
  • 3 phase.
  • Open dripproof (ODP).
  • Premium efficient.
  • Westcoast shaft - footed.
  • Class F Insulation, Class B Rise At Service Factor.
  • Rolled Steel Frame.
  • Aluminum End Shields 140-250, Cast Iron End Shields 280-320.
  • Oversized Ball Bearings with Locked Shaft End Construction.
  • Premasked Mylar Nameplate.
  • F1 Assembly Position.
  • Regreasable Bearings 180 Frame & Up, Lifting Provisions 210 Frame & Up.
  • Double Shielded Bearings.
  • 40 C Ambient, NEMA Design B Performance On 60 Hertz Sine Wave Power.
  • JM Shaft For Mechanical Seal.
  • JM Shaft on 210 Frame and Smaller; JP Shaft on 250 and 280 Frame.

Similar HVAC Fan Motor Products

Free Shipping
$1,520.05Each

Usually Ships 2-4 Weeks

US Motors
Visit The US Motors Store
See more US Motors Fan & Blower

Product Specifications

Part NumberDJ10P2DJ
Electrical Phase3 Ph
Horsepower10
Input Frequency60 Hz
Maximum Voltage208V-230V/460V
RPM1765
Wattage7500W
Product Dimensions22.31-in X 9.42-in X 9.96-in
Weight105.00-lb
UPC786382116071

Shop Top 100 HVAC System & Supply Products.

View other HVAC Fan Motor Best Sellers.

Manufacturer Description

10 HP, 1765 & 1455 RPM, DJ10P2DJ, 208-230/460 & 190/380 V, 60 & 50 HZ, 215TCZ
