US Motors Aqua-Shield Pro Pool & Spa Motor, 48Y, 3450RPM, 2.25HP, 115V/208V-230V
US Motors TEQ225
US Motors' Aqua-Shield Pro pool & spa motor has 48Y FRME, 3450 RPM, 2.25 HP and rated for 115V/208V-230V. It has a square flange with 1/2-20 UNC-2A shaft threads. Check out more US Motors products at HomElectrical today!
Image may not depict product actual color, inclusions or accessories
Similar HVAC Fan Motor Products
US Motors TEQ225 Description
- Motor Enclosure: TEFC.
- HP: 2.25.
- Poles: 2.
- Number of Speeds: 1.
- RPM: 3450.
- Hertz: 60.
- Volts: 115/208-230.
- FRME: 48.
- Shaft Code: Y.
- Stator Diameter: 5.5.
- Stack: 3.75.
- Mounting: Square flange.
- Motor Type: FHP.
- Rotation: CW Lead End.
- AQUA-SHIELD PRO TEFC Pool and Spa motor.
- Switchless design 5.5-in frame diameter.
- Square flange category S.
- Finned aluminum frame IPX5.
- THP rated 1081 design.
- Shaft Threads - (Square Flange) 1/2-20 UNC-2A or (C-Flange) 7/16-20 UNF-2A.
- 50 C Ambient.
- 1081 Design.
- Continuous Duty.
- Class B Insulated.
- Totally Enclosed, Fan Cooled, IPX5 Enclosure.
- 300 Series Stainless Steel Shaft.
- Thermally Protected.
- 5.5-in Diameter Frame.
- Triple Bearing Protection.
- Finned Aluminum Frame.
- cUL/UL Listed, CSA US.
- 1 Year Warranty.
$456.32Each
SKU EMB-TEQ225
Usually ships 2-4 Weeks
Product Specifications
| Part Number | TEQ225 |
| Electrical Phase | 1 Ph |
| Inner Package | 1 |
| Maximum Voltage | 115V/208V-230V |
| RPM | 3450 |
| Warranty | 1 Yr |
| Weight | 31.50-lb |
